Paint Pocket
 |
 |
Länk till Paintpockets hemsida
PaintPocket färgfälla har en hög avskiljning av färgpartiklar (avskiljningsgrad på 99,86%).
Filtren finns i följande storlekar:
| Paint pocket 24-50 | dim 609 * 15.240 mm |
| Paint pocket 36-50 | dim 914 * 15.240 mm |
| Paint pocket 45-50 | dim 1.143 * 15.240 mm |
Paint Pockets Overspray Arrestor Specifications:
| * Overall Arrestence Efficiency | 99,84% |
| Fractional Arrestance Efficiency | |
| 20µ paint droplets | 100% |
| 10µ paint droplets | 99,8% |
| 5µ paint droplets | 84,5% |
| 2,5µ paint droplets | 4,2% |
| Holding Capacity | Up to 6 Ib/sq ft | Upp till 29 kg/m² |
| Recommended Avarage Air Velocity | 100-250 FPM | 0,5-1,25 m/s |
| Initial Pressure Drop (100 FPM) | 0,06 in W.C | 15 Pa |
| * Maximum Pressure Drop | 1,00 in W.C | 250 Pa |
| Flammability Raiting | UL Class II Listing | |
| Filter Construction | High Loft, Multi Ply Non-wowen Polyester |
